LU‑DTDP2 Desktop Liquid Filling Machine

Enquire now Arrange a Demonstration Call Now

Machine overview

Key information to help you specify the right configuration.

LU-DTDP2 Desktop Liquid Filling Machine preview

The Lancing UK LU-DTDP2 Desktop CNC Diaphragm Pump Liquid Filling Machine with Conveyor is designed for efficient, precise, and automated liquid filling. Equipped with an infrared sensor, it automatically stops when no bottles are detected, ensuring accuracy and reducing waste.

Send your product details, container or pack format and target output to discuss configuration, pricing guidance and lead times.

This page lists output at 1500-3000 bottles/hour(depends on botle size and liquid); site requirements including Power Supply Voltage: 110/220V 50-60HZ; Power: 250W. Lancing UK can review your product, container or pack format, target speed and site requirements to confirm the right configuration before quotation.

Throughput
1500-3000 bottles/hour(depends on botle size and liquid)
Actual throughput depends on the product, pack format, changeovers and the wider line setup.
Format range
Matched to your container, closure or pack format
Compatibility is checked against your real bottle, cap, label, pouch or carton dimensions.
Utilities
110/220V 50-60HZ; 250W
Power, air and footprint requirements vary with the final machine configuration and options.

Specifications

Reference specification table. Final configuration is confirmed with the agreed scope, options and pack format.

ParameterValue
ParameterValue
About50kg
Power Supply Voltage110/220V 50-60HZ
Power250W
Maximum flow velocity4000m/min (base on water)
Working speed1500-3000 bottles/hour(depends on botle size and liquid)
Air pressure0.3-0.4MPa
Filling accuracy≤+1% (For water)
Diameter of Flling Nozzle6/8mm
Delay Range0.01-999.9s
Count Range1-99999 Times
Machine Size1350x710x600mm
Machine WeightAbout 50kg
Filling Volume3-1000ml(220V)3- 500ml(110V)since the power of 110v machine is not large, so we recommend 3-500ml for each nozzle

CAD / dimensions

Site requirements

  • Power Supply Voltage: 110/220V 50-60HZ
  • Power: 250W
  • Air pressure: 0.3-0.4MPa
  • Machine size: 1350x710x600mm
For the most accurate proposal, include the product, container or pack dimensions, closure or label format, required units per hour and available utilities.

Detailed layout and dimension drawings can be supplied during quotation and project planning where required.

Quick answers

Practical information to help compare this machine with alternative packaging solutions.

What is LU‑DTDP2 Desktop Liquid Filling Machine used for?

The Lancing UK LU-DTDP2 Desktop CNC Diaphragm Pump Liquid Filling Machine with Conveyor is designed for efficient, precise, and automated liquid filling. Equipped with an infrared sensor, it automatically stops when no bottles are detected, ensuring accuracy and reducing waste. This page lists output at 1500-3000 bottles/hour(depends on botle size and liquid); site requirements including Power Supply Voltage: 110/220V 50-60HZ; Power: 250W.

What output can LU‑DTDP2 Desktop Liquid Filling Machine achieve?

This page lists output at 1500-3000 bottles/hour(depends on botle size and liquid). Actual throughput depends on the product, container or pack format, changeover requirements and the wider line setup.

What formats does LU‑DTDP2 Desktop Liquid Filling Machine suit?

Suitability depends on the product characteristics, fill range, container format and how much adjustment is needed between SKUs.

What utilities or site requirements should I plan for?

Typical requirements listed on this page include Power Supply Voltage: 110/220V 50-60HZ; Power: 250W; machine size: 1350x710x600mm.

Can Lancing UK help match this machine to my application?

Yes. Lancing UK can review the product, pack format, required output, utilities and line-integration needs to confirm the right configuration before quotation.
