Key information to help you specify the right configuration.
The LU-VTGF8A is a high-performance 8-head liquid and paste filling machine equipped with servo-driven gear pumps. Designed for medium to large volume applications, it supports a wide filling range from 50ml to 5000ml, making it ideal for products like shampoo, conditioner, lotion, and detergent.
Configuration is confirmed against the product, pack format, utilities and required output. Lancing UK can review your product, container or pack format, target speed and site requirements to confirm the right configuration before quotation.
Representative machine images.
Reference specification table. Final configuration is confirmed with the agreed scope, options and pack format.
| Parameter | Value |
|---|---|
| Parameter | Value |
| Model | LU-VTGF8A Power Supply: 110/220V 50-60HZ 5KW Filling Pump: Gear Pump Max Flow Rate: 120L Filling Range: 50-5000 ml Bottle Size: Customizable Working Speed: About 24-40 bottles/min (based on 5L filling volume) Filling Accuracy: About ±0.5% Air Pressure: About 0.5-0.8 MPa Machine Size: About 492012701950 mm (LWH) Package Size: About 272013502120 mm Package Weight: About 630 kg |
| Gear pumps are commonly used for transferring | Lubricating oils (e.g., machinery oil, hydraulic oil, engine oil) Fuels (e.g., diesel, heavy oil, light oil) Chemical liquids (e.g., resin, paint, additives) Food-grade liquids (e.g., syrup, chocolate paste, vegetable oil) - requires a stainless steel food-grade gear pump Polymers and viscous materials (e.g., glue, bitumen) 👉 If you need a food-grade filling machine, feel free to contact us for customized solutions! |
Power, air and footprint requirements depend on the final machine specification and any selected options.
Detailed layout and dimension drawings can be supplied during quotation and project planning where required.
Practical information to help compare this machine with alternative packaging solutions.
The LU-VTGF8A is a high-performance 8-head liquid and paste filling machine equipped with servo-driven gear pumps. Designed for medium to large volume applications, it supports a wide filling range from 50ml to 5000ml, making it ideal for products like shampoo, conditioner, lotion, and detergent. Configuration is confirmed against the product, pack format, utilities and required output.
Output depends on the product, fill volume, nozzle or dosing arrangement, container handling and the required level of accuracy.
Suitability depends on the product characteristics, fill range, container format and how much adjustment is needed between SKUs.
Power, air, footprint and installation requirements depend on the final specification and are confirmed at quotation stage.
Yes. Lancing UK can review the product, pack format, required output, utilities and line-integration needs to confirm the right configuration before quotation.
We’ll confirm suitability, options, integration, and realistic throughput for your product.
Send a message and we’ll respond with configuration options, pricing guidance and lead times.
If LU‑VTGF8A Automatic Viscous Liquid Filling Machine is close to the right shortlist, use these pages to compare the wider application, line challenge, guide and support routes around it.
