Machine overview
Key information to help you specify the right configuration.
The Lancing UK LU-YT4T-4PM Automatic Paste/Liquid Filling Machine is engineered for precision filling of viscous products such as chocolate, honey, and chili paste. Equipped with integrated mixing and heating functions, it ensures consistent texture and temperature control during filling. With adjustable filling ranges and speeds, it supports a wide variety of container sizes. Compatible with automatic capping and labeling systems, this machine streamlines production for industries including food, beverage, and daily chemicals. LU-YT4T-4PM Automatic Paste/Liquid Filling Machine – Technical Specifications Parameter Specification Machine Model LU-YT4T-4PM Voltage 110V / 220V, 50–60Hz, 600W Filling Range 5–100ml / 10–300ml / 50–500ml / 100–1000ml / 300–3000ml / 1000–5000ml Working Speed 20–50 bottles/min (depends on bottle size & material) Heating Temperature Approx. 0–300°C Mixing Speed Approx. 1200 r/min Filling Accuracy < ±1% Air Pressure Requirement 0.5–0.7MPa Conveyor Size (L × W) Approx. 2000 × 100mm Filling Nozzle Diameter φ10mm Air Compressor Connector Size φ8mm Machine Dimensions (L × W × H) Approx. 975 × 1020 × 2010mm Machine Weight Approx. 329kg Package Dimensions (L × W × H) Approx. 1660 × 1130 × 2130mm Package Weight Approx. 329kg
Throughput
Configurable (confirm during quote)
Throughput depends on product, format and operator workflow.
Format range
Formats adjustable (bottle/closure dependent)
Configured to your bottle, closure and fill volume.
Utilities
Site utilities to be confirmed
Voltage, air and installation requirements confirmed for your site.
