Machine overview
Key information to help you specify the right configuration.
The Lancing UK LU-TB990 is a high-performance automatic labeling machine designed for single or double-sided labeling on round and square bottles. With a working speed of up to 150 bottles per minute and ±1mm labeling accuracy, it ensures fast and precise application across a wide range of bottle sizes. Compatible with automatic filling and capping systems, the LU-TB990 supports seamless integration into fully automated production lines. Ideal for industries such as cosmetics, food, beverage, and pharmaceuticals, this machine enhances labeling efficiency and consistency for flat and round containers. LU-TB990 Labeling Machine – Technical Specifications Parameter Specification Machine Model LU-TB990 Power Supply 110V / 220V, 2500W Working Speed 30–150 bottles/min (depends on bottle & label size) Labeling Accuracy ±1mm Suitable Bottle Diameter ≤100mm Bottle Dimensions (W × H) Width: 30–100mm
Height: 50–350mm Label Size (L × W) Length: 15–300mm
Width: 15–150mm Label Roll Outer Diameter Ø280mm Label Roll Inner Diameter Ø76mm Applicable Bottle Types Flat / Round Bottles Machine Dimensions (L × W × H) Approx. 2720 × 1550 × 1650mm Machine Weight Approx. 389kg Package Dimensions (L × W × H) Approx. 1930 × 1000 × 1690mm Package Weight Approx. 450kg
Height: 50–350mm Label Size (L × W) Length: 15–300mm
Width: 15–150mm Label Roll Outer Diameter Ø280mm Label Roll Inner Diameter Ø76mm Applicable Bottle Types Flat / Round Bottles Machine Dimensions (L × W × H) Approx. 2720 × 1550 × 1650mm Machine Weight Approx. 389kg Package Dimensions (L × W × H) Approx. 1930 × 1000 × 1690mm Package Weight Approx. 450kg
Throughput
Configurable (confirm during quote)
Throughput depends on product, format and operator workflow.
Format range
Formats adjustable (bottle/closure dependent)
Configured to your bottle, closure and fill volume.
Utilities
Site utilities to be confirmed
Voltage, air and installation requirements confirmed for your site.
